Pulse Vacuum Sterilizer LT-VS407

Pulse Vacuum Sterilizer LT-VS407 offers 0.36 m³ chamber for efficient sterilization. It features multiple adjustable sterilization modes controlled by an automated microcomputer system. Equipped with stainless-steel construction reinforced by advanced welding, it ensures long-lasting durability. Designed with electrolytic polishing and multi-channel external steam heating, it meets food-grade standards for safe operation. Our Sterilizer is ideal for decontaminating food processing equipment, media, glassware, and fabrics.

Catalog

Qty:

$ 35,794.00

Specifications

Volume 0.36 m³
Design Temperature 144°C
Sterilization Temperature Range 105°C to 139°C
Inner Cavity Design Pressure -0.1 to 0.3 MPa
Inner Cavity Working Pressure -0.1 / 0.25 MPa
Jacket Design Pressure 0.3 MPa
Jacket Working Pressure 0.25 MPa
Inner Cavity Water Pressure Test 0.39 MPa
Jacket Water Pressure Test 0.52 MPa
Temperature Uniformity ±1°C
Limiting Vacuum -94.3 kPa
Leakage Rate ≤1.3 kPa / 10 min
Temperature Difference 15°C
Power Consumption 1.2 kW
Power Supply 380V, 50Hz
Chamber Dimension 1000 × 600 × 600 mm
Housing Dimensions 1260 × 1270 × 1740 mm
Weight 800 kg

Features

  • Single-door configuration
  • Intuitive color touch screen
  • Stage-wise heating system
  • Vacuum monitoring function
  • Four-sided V-shaped chamber base
  • Integrated safety features

Application

  • Pulse Vacuum Sterilizer LT-VS407 is ideal for sterilizing food processing equipment, containers, media, glassware, scientific instruments, surgical tools, fabrics, and other supplies across the food industry, healthcare facilities, and laboratory settings.
